Industrial Sand Filter Water Treatment

Material: SS304、SS316 or Q235 carbon steel （customized）
Anticorrosive measures: 1） Internal coating of epoxy resin；
2） Inner lining of rubber；
3） Inner lining of fiberglass

Send Inquiry

Product Introduction

product-1117-657

Backwashing Carbon Filter

Product name: Industrial sand filtration water treatment

Material: SS304, SS316 or Q235 carbon steel

Anti-corrosion measures: internal coating with epoxy resin; rubber lining; fiberglass lining

Specifications and dimensions: φ200mm~ φ3500mm

Fully automatic backwash filters (self-cleaning filters) include automatic backwash quartz sand filters and automatic backwash activated carbon filters. Automatic backwash operation is achieved by adjusting the electric valve by setting time or pressure difference. Generally, automatic control valve and PLC microcomputer or time relay control are used.

1. Advantages of automatic valve control: low price, easy to install, debug and operate. Disadvantages: The flow rate is within 30 tons/hour.

2. Advantages of PLC fully automatic control and time relay: the flow rate can reach 120 tons/hour and has multiple control points. Disadvantages: The price is relatively expensive.

Industrial sand filters are essential for effective water treatment in a variety of industrial environments. Designed to remove suspended solids and impurities from water, these filters work by using a layer of sand as the filter media.

Industrial sand filtration systems are simple and rely on basic technology. A sand filter is a container filled with specially graded sand media that captures and filters impurities in the water as it passes through the filter. Water enters the top of the filter, passes through the sand media, and exits through the bottom layer of the filter.

This filtration process is highly efficient and produces excellent water quality. The sand used in filters is carefully selected and graded to ensure the particles are the right size and have the surface area required for optimal filtration.

Best Activated Carbon Water Filter

Industrial sand filtration systems are ideal for water treatment in applications such as cooling towers, process water, municipal water treatment and recirculation systems. It removes impurities from water and slows the build-up of scale and biofilm in pipes and other equipment.

Industrial sand filters are easy to maintain and operate. Filters require regular backwashing to remove accumulated impurities and keep the sand clean and efficient. Regular maintenance of your filter ensures it functions optimally and extends its lifespan.

Model	Sc02-300	Sc02-400	Sc02-500	Sc02-600	Sc02-700	Sc02-800
Spec.	Φ300×1600	Φ400×1600	Φ500×1650	Φ600×1700	Φ700×1600	Φ800×1600
Flowing quantity	0.5~1m³/h	1~1.5m³/h	1.5~2m³/h	2~4m³/h	4~6m³/h	6~8m³/h

Model	Sc02-900	Sc02-1000	Sc02-1200	Sc02-1400	Sc02-1500	Sc02-1600
Spec.	Φ900×2400	Φ1000×2500	Φ1200×2700	Φ1400×2800	Φ1500×2900	Φ1600×2900
Flowing quantity	7~9m³/h	8~11m³/h	10~14m³/h	12~18m³/h	14~22m³/h	18~25m³/h

Model	Sc02-1800	Sc02-2000	Sc02-2200	Sc02-2400	Sc02-2500	Sc02-2600
Spec.	Φ1800×3200	Φ2000×3300	Φ2200×3500	Φ2400×3500	Φ2500×3600	Φ2600×3700
Flowing quantity	24~32m³/h	28~40m³/h	35~45m³/h	40~55m³/h	45~60m³/h	55~65m³/h

Model	Sc02-2700	Sc02-2800	Sc02-3000	Sc02-3200	Sc02-3400	Sc02-3500
Spec.	Φ2700×3750	Φ2800×3800	Φ3000×3850	Φ3200×3950	Φ3400×4100	Φ3500×4300
Flowing quantity	60~72m³/h	68~85m³/h	75~95m³/h	90~110m³/h	100~125m³/h	110~140m³/h

Original Seal Standard Package

Identify The Authenticity Of The Label

Packed In Steel Bottles
